Technical data

.

Output power RMS / max.

- @ 4 Ohms 4 x 35 / 70 Watts (Font/Rear channels)

- @ 2 Ohms 4 x 50 / 100 Watts (Font/Rear channels)

 Subwoofer output @ 2 Ohms 1 x 160 / 320 Watts (4 channels each 40 / 80 Watts)

Amplifier technology Class AB

DSP type Audio signal processor

Signal converters A/D: BurrBrown

D/A: BurrBrown

Additional features Variable input sensitivity, fully stabilized internal power supply with Start-Stop capability, 56 Bit digital signal processing, internal memory for 2 different sound setups, USB input, ADEP.2 circuit, Auto Remote switch, MEC slot, input for optional remote control, stereo line outputs with balanced output transformers (floating ground)

Dimensions (H x W x D) 44 x 185 x 139 mm /

1.73 x 7.28 x 5.47“
