Technical data

.

Output power RMS

- @ 4 Ohms 8 x 55 Watts

- @ 2 Ohms 8 x 70 Watts

Amplifier technology Class HD

Inputs 6 x Highlevel speaker input

1 x Optical SPDIF (12 - 96 kHz)

1 x Remote In

Input sensitivity Highlevel 5 - 11 Volts

Outputs 8 x Speaker output

2 x RCA / Cinch (mono)

2 x Remote Out

Output voltage RCA / Cinch 3 Volts RMS

Frequency response 20 Hz - 22,000 Hz

DSP resolution 64 Bit

DSP power 295 MHz (1.2 billion MAC operations/second)

Sampling rate 48 kHz

DSP type Audio signal processor

Signal converters A/D: BurrBrown

D/A: BurrBrown

Additional features Class HD technology with dynamically controlled

power supply, 32 Bit CoProcessor, ADEP.3 circuit, Smart Control Port, Start-Stop capability, USB, MEC slot, Auto Remote switch, galvanically isolated Line Outs

Dimensions (H x W x D) 44 x 185 x 164 mm /

1.73 x 7.28 x 6.46“
