Component | Three way coaxial |
Size mm (in.) | (7 x 10) |
Power Handling - Continuous W | 150 |
Power Handling - Peak W | 300 |
Impedance Ohm | 4 |
Depth mm (in.) | 110 (4.3 in.) |
Woofer Voice Coil Ø mm (in.) | 25 (1.0) |
Frequency Response Hz | 40 ÷ 21k |
Woofer Magnet size D x d x h mm (in.) | 90 x 32 x 17 (3.5 x 1.3 x 0.7) |
Weight of one speaker kg (lb.) | 1,35 (2.97) |
Woofer Magnet | High density flux ferrite |
Tweeter Magnet | High density flux ferrite |
Cone | Water-repellent pressed paper |
Dome | Water-repellent pressed paper |
D mm | 181 |
Re Ohm | 3,3 |
Fs Hz | 69 |
Vas I | 23,0 |
Mms g | 22,0 |
Cms mm/N | 0,24 |
BL T*m | 4,9 |
Qts | 1,06 |
Qes | 1,31 |
Qms | 5,50 |
Spl dB | 93 |
