Kodas:
Component | Woofer |
Size mm (in.) | 165 (6.5) |
Power Handling - Continuous W | 100 |
Power Handling - Peak W | 200 |
Impedance Ohm | 3 |
Voice Coil Ø | 25 (1) |
Frequency Response Hz | 45 ÷ 4,5k |
Magnet size D x d x h mm (in.) | 95 x 45 x 17 (3.74 x 1.77 x 0.67) |
Weight of one speaker kg (lb.) | 1.2 (2.65) |
Magnet | High density flux ferrite |
Cone | Pressed-pulp cone with cotton fibers |
Xmech mm (in.) | ±7.5 (0.3) |
D mm | 132 |
Re Ohm | 2,6 |
Fs Hz | 75 |
Le mH | 0,28 |
Vas I | 8 |
Mms g | 15,1 |
Cms mm/N | 0,3 |
BL T*m | 5,45 |
Qts | 0,56 |
Qes | 0,63 |
Qms | 5,2 |
Spl dB | 94 |
