Component | Mid-range |
Size mm (in.) | 70 (3) |
Power Handling - Peak W | 100 |
Power Handling - Peak Note | (Hi-Pass filtered @ 250Hz - 12dB Oct.) |
Impedance Ohm | 4 |
Voice Coil Ø | 20 (0.8) |
Frequency Response Hz | 200 - 20k |
Magnet size D x d x h mm (in.) | 45 x 25 x 3,5 (1.77 x 0.98 x 0.13) |
Weight of one speaker kg (lb.) | 0,21 (0.46) |
Magnet | Neodymium |
Cone | Pressed-pulp cone with cotton fibres |
D mm | 65 |
Re Ohm | 3,8 |
Fs Hz | 110 |
Le mH | 0,05 |
Vas I | 1,1 |
Mms g | 2,7 |
Cms mm/N | 0,7 |
BL T*m | 3,3 |
Qts | 0,57 |
Qes | 0,67 |
Qms | 4 |
Spl dB | 90 |
