Technical data

.

Power RMS / max. P 120 / 170 Watts

(highpass > 3,000 Hz at 12 dB/Oct.)

Impedance Z 4 Ω

DC resistance Re 3.4 Ω

Frequency response 1,800 - 25,000 Hz

Resonance frequency Fs 760 Hz

Sensitivity SPL

93 dB @ 2.83V / 1m

90 dB @ 1W / 1m

Voice coil diameter ø 28 mm / 1.10"

Cone area Sd 6.2 cm²

Moving mass Mms 0.32 g

Cone material Silk dome with a visco-elastic Acronal coating on both sides
