Technical Specs  :

----------------------------

D-Class

6Ch mode

@4Ω: 85 x 4 + 110 x 2

@2Ω: 140 x 4 + 185 x 2

Ch1-4 @4Ω, Ch5-6 @1Ω: 75 x 4 + 340 x 2

Ch1-4 @2Ω, Ch5-6 @1Ω: 140 x 4 + 300 x 2

5Ch mode

@4Ω: 85 x 4 + 370 x 1 (Ch5/6 bridged)

@2Ω: 130 x 4 + 600 x 1 (Ch5/6 bridged)

4Ch mode

@4Ω: 280 x 2 (bridged) + 110 x 2

@2Ω: 130 x 2 + 260 x 1 + 600 x 1

3Ch mode

@4Ω: 280 x 2 + 370 x 1 (Ch5/6 bridged)

280 x 2 (Ch1-4 @4Ω) + 600 x 1 (Ch5/6 bridged @2Ω)

Dimension : 314 mm x 155 mm x 48 mm
